24VAC 48VAC Power Solutions From Snaptec
Welcome to our product informer. At Snaptec We can offer you ac/dc power supplies and DC/AC Inverters for 24VAC and 48VAC applications, below is a list of some of the products available.

SWX10-60: 24VAC IN to DC Out 10W to 60W Isolated

<u>SWX10-60:</u>  24VAC IN  to DC Out 10W to 60W Isolated

The new SWX series of AC/DC power supplies with 24VAC input are ideal for many industrial applications.

Some of the features of the new series include:

  • Suitable for 24VAC input applications
  • Wide input range: 17-40VAC
  • Single output options from 5 ~ 30V
  • Non standard output voltages possible
  • Panel mounting and Din rail Mounting case with screw terminals
  • Six sided Nickel-Coated Copper shield converter modules
  • High operating temperature up to 70 C
  • Suitable for a wide range of industrial applications
  • Full isolation between input and output
  • Power ratings 8W , 10W , 15W , 20W , 30W , 40W , 60W


  • The SWX series of AC/DC power supplies with 24VAC input find applications in security systems, irrigations systems , fibre optics transmitters , industrial control equipment , communications equipment.

    For further information please refer to the following website: SWX Series 24VAC IN 10W,15W,20W,30W,40W,60W

    SWX72: 24VAC In to DC Out 72W Isolated

    <u>SWX72:</u>  24VAC In to DC Out 72W   Isolated

    The SWX72 series of AC/DC power supplies with 24VAC input are ideal for many industrial applications.

    Some of the features of the new series include:

  • AC/DC Suitable for 24VAC input applications
  • Wide range input 17 ~ 34VAC
  • Single output options from 5 ~ 30VDC
  • Panel / Din Rail mounting case with screw terminals
  • Suitable for a wide range of industrial applications
  • Power rating 72W


  • The SWX72 series of AC/DC power supplies with 24VAC input find applications in security systems, irrigations systems , fibre optics transmitters , industrial control equipment , communications equipment.

    For further information please refer to the following website: SWX72 Series 24VAC IN 72W

    SWX150: 24VAC IN to DC Out 150W Isolated

    <u>SWX150:</u>  24VAC  IN  to DC Out 150W Isolated

    The SWX150 series of AC/DC power supplies with 24VAC input are ideal for many industrial applications and rated up to 150W.

    Some of the features of the new series include:

  • AC/DC Suitable for 24VAC input applications
  • Wide range input 20 ~ 34VAC
  • Single output options from 5 ~ 48VDC
  • Panel mounting case with screw terminals
  • High operating temperature up to 70°C
  • Suitable for a wide range of industrial applications


  • For further information please refer to the following website: SWX150 Series 24VAC IN 150W

    SWX48: 48VAC IN to DC Out 10W to 40W Isolated

    <u>SWX48:</u>  48VAC IN  to DC Out  10W to 40W  Isolated

    The new SWX48 series of AC/DC power supplies with 48VAC input are ideal for many industrial applications.

    Some of the features of the new series include:

  • Suitable for 48VAC input applications
  • Input range: 40-60VAC
  • Single output options from 5 ~ 48V
  • Panel mounting and Din rail Mounting case with screw terminals
  • Built in high performance converter modules
  • Suitable for a wide range of industrial applications


  • For further information please refer to the following website: SWX48 Series 48VAC IN 10W,20W,40W

    SLS24: DC IN to 24VAC Out Inverters 250W to1KW

    <u>SLS24:</u>  DC IN   to 24VAC Out Inverters 250W to1KW

    The SLS24 series of DC/AC power inverters with 24VAC output are designed for 24VAC loads that require high power ratings , starting from 250W all the say to 1KW with DC inputs from 12V to 125VDC

    Some of the features of the new series include:

  • Industrial Grade 24VAC Output Inverters
  • Unmatched surge capacity
  • DC input options: 12, 24V, 48V, 110V, 125V(standard)
  • Pure Sinewave output
  • High efficiency - up to 92%
  • AC overload, AC short circuit protection
  • Thermal, DC voltage high/low protection
  • Sophisticated auto-start system
  • Fully Isolated AC / DC via toroidal transformer
  • Low standby current
  • High quality construction, Reliable product


  • For further information please refer to the following website: SLS24 Series DC/AC Inverters 24VAC outptut 250W 300W 600W 1000W

    CNB-C50: DC In to 24VAC Out Inverters 50W

    <u>CNB-C50:</u> DC In to 24VAC Out Inverters 50W

    The CNB-C50 is a low cost inverter designed to power small 24VAC loads from a 12V or 24V supply
    Some of the features of the new series include:

  • Small Size solution to supply 24vac.
  • Power rating : 50W
  • Input voltage options: 12VDC 24VDC
  • Output voltage: 24VAC 50Hz Pure Sinewave
  • Numerous applications in security and control systems


  • For further information please refer to the following website: CNB- C50 dc ac inverter 24vac 50w

    CSI24: DC In to 24VAC Out Inverters 50W 100W

    <u>CSI24:</u>  DC In to 24VAC Out Inverters  50W 100W

    The CSI24 is an industrial grade DC/AC Inverter range designed for heavy duty industrial and security applications. Input voltages of 12V 24V 48V are standard
    Some of the features of the new series include:

  • Filtered 24VAC 50Hz output
  • DC Input voltage options: 12V, 24V & 48V
  • Convection cooled: No fans
  • Suitable for CCTV applications requiring clean 24VAC
  • Fully isolated input / output 1000VDC
  • Over voltage protection
  • Overload and short circuit protection
  • MTBF > 150,000hrs
  • Special input / output combinations on request.


  • For further information please refer to the following website: CSI24 series dc to ac inverters 24vac 50W 100W

    SLS48: DC In to 48VAC Out Inverters 300W to 1KW

    <u>SLS48:</u>  DC In to 48VAC Out Inverters 300W to 1KW

    The SLS48 series of DC/AC power inverters with 24VAC output are designed for 48VAC loads that require high power ratings , starting from 300W all the way to 1KW with DC inputs from 12V to 125VDC

    Some of the features of the new series include:

  • Industrial Grade 48VAC Output Inverters
  • Unmatched surge capacity
  • DC input options: 12, 24V, 48V, 110V, 125V(standard)
  • Pure Sinewave output
  • High efficiency - up to 92%
  • AC overload, AC short circuit protection
  • Thermal, DC voltage high/low protection
  • Sophisticated auto-start system
  • Fully Isolated AC / DC via toroidal transformer
  • Low standby current
  • High quality construction, Reliable product
  • Snaptec Australia specializes in the following product areas:
    DC UPS Systems - Battery Chargers - DC Backup Solutions
    DC/DC Converters
    AC/DC Power Supplies
    DC/AC Inverters - Pure Sinewave
    Battery Chargers - Multistep
    AC/AC Transformers, Line Conditioners, Frequency Converters
    AC/AC UPS Systems
    Laboratory Power Supplies & DC Electronic Loads
    Industrial Batteries
    Solar Power Products
    Power Supply Accessories
