12LFP42HR - 12V 42AH High discharge

  • Cycle life: >2000 cycles (100% DoD to 80% of original capacity) @ 25°C
  • Max. continuous discharge current: 100A
  • Standard charge current: 8.4A
  • Max. cont. charge current: 42A
  • Charge voltage: 14.2V - 14.6V (14.2V recommended)
  • Operating Discharge temperature: -20°C to +60°C
  • Operating Charge temperature: +0°C to +45°C
  • Storage temperature: -20°C to +45°C
  • Series Connection: Up to 4S
  • Parallel Connection: Nil
  • ARF240 240W Ultra Compact Power Supply

  • Ultra Compact Size: 4.1 x 2.46 x 1.54 Inches
  • Enclosed / Open Frame / U Bracket Switching Power Supply
  • Universal Input Range 90-264VDC
  • High Efficiency up to 94%
  • O/P Voltage: 12,24,48VAC
  • No Load Power Consumption<0.5W
  • -30°C to +80°C Wide Range Operation Temperature
  • Built-in 12V / 0.5A Fan Supply(ARF240O)
  • Operating Altitude 5000M
  • Active PFC Function
  • I/O Isolation 4000VAC
  • EMI for Both Class I (with PE) and Class II (without PE) Configuration
  • UL / IEC / EN 62368-1 Safety Approvals
  • 1RU 19" Rack Mount Distribution Din Rail Panel

    1RU 19" Rack Mount Distribution Panel

    SWX72 72W

  • AC/DC Suitable for 24VAC input applications
  • Wide range input 17 ~ 34VAC
  • Single output options from 5 ~ 48VDC
  • Panel / Din Rail mounting case with screw terminals
  • Suitable for a wide range of industrial applications
  • Models with power ratings 72W
  • Chassis Mount or Din Rail Mount
  • New product range: VE.Can SmartSolar MPPTs

    19" Rack Mount Distribution Panel

    SDP-20 19" Rack Mount Distribution Panel

    19" Rack Mount Distribution Panel

    DC/AC Inverters with 24VAC Output

    DC/AC Inverters with 24VAC Output

    ELR9000 DC Electronic loads

    Programmable DC Electronic loads with grid feed capability 80V to 1500V 3.5KW to 10.5KW

    Snaptec releases new lab power supply

    Snaptec releases new lab power supply

    New Industrial Lithium Ion Battery Chargers 100W - 250W - 500W - 750W

    New Industrial Lithium Ion Battery Chargers 100W - 250W - 500W - 750W

    Victron Energy Products

    Snaptec is a major distributor of Victron Energy Products , this inlcudes sinewave inverters, sinewave inverters/chargers, battery chargers, transfer switches, battery monitors and more. Victron Energy has a strong, unrivalled reputation for technical innovation, reliability, and build quality. Victron products are widely considered to be the professional choice for independent electric power.

    Snaptec releases new Din rail mount DC UPS

    The CBU V2 , is the latest development in the snaptec range of DC UPS units. with increased fetatures and improved performance, this range of DC UPS units offers an off the shelf solution for many DC backup applications

    New 3W PCB mount AC/DC Power Supply

    New Minature 3W PCB mount AC/DC power supply offers increased space saving and high efficiency performance

    High Power Variable Power Supplies 5KW 10KW 15KW

    The new PS8000-3U is a range of high power industrial variable power supplies with a constant output power stage. Available in 3 power ratings of 5KW , 10KW and 15KW

    Snaptec releases new 24V DC UPS unit

    New DC UPS for 24V systems that operates on a single 12V battery

    Snaptec releases new programmable dc power supplies

    High quality fully programmable dc power supplies at an incredible price. Full computer control using RS232 or USB make this power supply a perfect choice for school labs , automation applications and industrial applications.

    Snaptec releases new AC/DC chassis mount programmable power supplies

    High quality fully programmable industrial chasiss mount power supplies with power rating from 320W to 1500W

    AC/DC Power Supplies with 24VAC Input

    For control systems that run on 24VAC, a wide range of power supplies to converter 24VAC to dc voltages from 3.3V to 48V at various power levels.

    AQFV480 AC/DC Power Supply 480W

    AQFV480 AC/DC Power Supply 480W in a compact size with active power factor correction

    QS40.241 compact 1 kW power supply

    Compact rugged ac/dc power supply with 24V 1KW output in a din rail mount case with single phase AC input.

    DC/DC Converters with 48VDC Output

    DC/DC converter with 48VDC output rated at 200W and 360W

    DC UPS Solutions for industrial applications

    Wide range of DC UPS solutions to back up DC load with 12V , 24V , 48V , 110VDC

    LED Power Supplies 30W to 300W

    Wide range of LED Power supplies are now offered ranging in power from 30W to 300W

    DC Backup solutions for emergeny lighting

    DC Backup solutions for emergeny lighting

    GB2-360 DC/DC Converter 360W

    GB2-360 DC/DC Converter 360W

    AQF240 240W Compact AC/DC Power Supply

    240W Compact AC/DC Power Supply

    GB Series DC/DC converters expanded

    Our GB series of DC/DC Converters has been expanded. The GB series are fully encapsulated rugged dc/dc converters, with inputs from 12V to 110VDC and outputs from 5V to 110VDC and now with power ratings of 30W , 60W , 120W , 150W , 180W , 240W , 300W and 360W. This GB series of converters can be customised for numerous applications. So if you need a non standard input / output combination we can still make it for you even if it is a 1 off.

    19 Inch rackmount inverters

    19 Inch rackmount inverters

    AC/DC Power Supplies with 24VAC Input

    Wide range of AC/DC Power Supplies with 24VAC Input

    AC/DC Power Supplies

    Wide range of AC/DC single output and multioutput power supplies. Starting form 1W up to 12KW in numerous configurations including vented case, external , pcb mount , 19" rack mount , wall mount. These power supplies are available in industrial grade, medical grade and commercial grade.

    New SWX 10 - 60 AC/DC Power Supplies with 24VAC Input

    The new SWX series of AC/DC power supplies with 24VAC input are ideal for many industrial applications.

    Some of the features of the new series include:

  • Suitable for 24VAC input applications
  • Wide input range: 12-40VAC
  • Single output options from 5 ~ 30V
  • Non standard output voltages possible
  • Panel mounting and Din rail Mounting case with screw terminals
  • Six sided Nickel-Coated Copper shield converter modules
  • High operating temperature up to 70° C
  • Suitable for a wide range of industrial applications
  • Full isolation between input and output
  • Power ratings 8W , 10W , 15W , 20W , 30W , 40W , 60W
  • The SWX series of AC/DC power supplies with 24VAC input find applications in security systems, irrigations systems , fibre optics transmitters , industrial control equipment , communications equipment. For further information please refer to the following website: SWX Series 24VAC IN 10W,15W,20W,30W,40W,60W

    SWX10 SWX20 SWX30 SWX40 SWX60

  • Suitable for 24VAC input applications
  • Wide input range: 17-40VAC
  • Single output options from 5 ~ 30V
  • Dual output models available upon request
  • Non standard output voltages possible
  • Panel mounting and Din rail Mounting case with screw terminals
  • Models with power ratings 10W 20W 30W 40W 60W
  • Suitable for a wide range of industrial applications
  • SWX75 75W

  • AC/DC Suitable for 24VAC input applications
  • Wide range input 17 ~ 34VAC
  • Single output options from 5 ~ 48VDC
  • Panel / Din Rail mounting case with screw terminals
  • Suitable for a wide range of industrial applications
  • Models with power ratings 75W
  • Chassis Mount or Din Rail Mount
  • NDD241 series dc/dc converters 110VDC 240VDC Input 240W

    For applications supplied by 110Vdc and 240Vdc asuch as energy distribution , back up or railway signalling with demaand for reliable conversion to standard lower voltages such as 24, 36, 48 or 72V.

    The new solution provided by Snaptec NDD241 series is aimed to respond to this increased market need in an elegant and compact manner offering also some unique features as the internal ORing circuity as standard.

    By providing only 56mm width and 240W power, together with reverse polarity protection, high efficiency, very wide input range, excellent temperature range, 4.2kVdc isolation and dual current limitation setup, the NDD241 series can be used in many applications requiring optimal use of space.

    DC Overcurrent Protection Device

    DC Overcurrent Protection Device

    HPV Series High Voltage Din Rail Mount Power Supplies

    Din Rail Mount High Voltage Power Supplies: 72VDC 110VDC 120VDC 150VDC 220VDC Industrial Power Supplies 480W 1000W

    CNB50 Inverters with 24VAC Output 50W

    DC/AC Inverters Output 24VAC 50W max with input voltage of 12VDC or 24VDC

    PROGRAMMABLE DC LABORATORY POWER SUPPLIES

    PROGRAMMABLE DC LABORATORY POWER SUPPLIES

    SWX10 to SWX60 AC/DC Power Supplies with 24VAC Input 10W to 60W

    The new SWX series of AC/DC power supplies with 24VAC input are ideal for many industrial applications.

    Some of the features of the new series include:

  • Suitable for 24VAC input applications
  • Wide input range: 12-40VAC
  • Can accept 24VDC and 48VDC Input as well
  • Single output options from 5 ~ 30V
  • Non standard output voltages possible
  • Panel mounting and Din rail Mounting case with screw terminals
  • Six sided Nickel-Coated Copper shield converter modules
  • High operating temperature up to 70°C
  • Suitable for a wide range of industrial applications
  • Full isolation between input and output
  • Power ratings 10W , 15W , 20W , 30W , 40W , 60W


  • The SWX series of AC/DC power supplies with 24VAC input find applications in security systems, irrigations systems , fibre optics transmitters , industrial control equipment , communications equipment.

    For further information please refer to the following website:

    SWX Series 24VAC IN 10W,15W,20W,30W,40W,60W

    19 Inch Rack Mount AC Distribution Panels

    Wide range of AC distribution panels 19 inch rack mount to suit numerous power distribution applications many models can be customised to suit specific customer application. Some of the features include:

  • AC Power strips for 19" rack mounting
  • Made from 1.2mm mild steel
  • Power coated in ripple black
  • Electrically earthed
  • Wide range of output sockets ( Australian sockets , IEC C13 , IEC C19 , UK sockets , Euro sockets)
  • Protected ac input with circuit breakers or fuses
  • Comes complete ready to install
  • Single phase up to 50A
  • Three phase 16A or 32A


  • For further information please refer to the following website:

    19 inch rack mount ac power strips

    MPPT Solar Regulators - The full range

    The blue power MPPT solar regulators from Snaptec offer a wide range of options to harness solar power. The range is quite extensive with models to charge 12V 24V 36V and 48V batteries with current ratings from 10A up to 100A. Input voltages coming form the solar panels can be as high as 250V on some models. The main features are:

  • Ultra-fast Maximum Power Point Tracking (MPPT)
  • Advanced Maximum Power Point Detection in case of partial shading conditions
  • Load output on the small models
  • Battery Life: intelligent battery management by load shedding
  • Automatic battery voltage recognition
  • Flexible charge algorithm
  • Over-temperature protection and power de-rating when temperature is high.


  • For further information please refer to the following website:

    Blue Solar MPPT regulators

    DCW20 DC/DC UPS 960W 12V 24V 48V

    DCW20 is a microprocessor controlled unit that can perform 2 functions:
  • 1. UPS rated 960W/20A usable in any system rated 12 to 48Vdc
  • 2. DC/DC converter (non isolated) rated 960W/20A usable in any combination of IN/OUT voltages 12 to 48Vdc


  • For the UPS function, it may use 1 battery of 12V, independently of the operating load voltage. For any supply voltages (12 to 48Vdc) it may use also multiple battery configuration (10 to 58Vdc). DCW20 monitors the voltage coming from a DC power supply and in case of power failure a backup battery is supplying the energy to the load. In normal condition the battery is kept charged by an integrated battery charger supporting various battery chemistries.

    As a DC/DC converter (no battery present) the input must be connected to the battery connector. The input voltage is converted to any output voltage as per the set-up.
